Canco Grating Clamp is a robust fastening solution designed for secure and reliable fixing of steel grating panels. Its strong construction and threaded fastening system provide firm clamping and easy installation for industrial, structural and flooring applications.
| Product Type | Grating fastener set — upper saddle, bolt and lower hook clip |
| Standards | Canco standard; for bar grating to ANSI/NAAMM MBG 531 |
| Material Grades | Mild steel hot dip galvanized, SS 304, SS 316 |
| Grating Bar Height | 20 mm to 60 mm bearing bars; 30 mm to 41 mm bar pitch |
| Thread Size | M8 to M12 (5/16" to 1/2") |
| Material Thickness | 3 mm to 6 mm |
| Support Flange Range | Clamps onto support flanges up to 25 mm thick |
| Finish | Hot dip galvanized, zinc plated, passivated stainless |
| Custom Options | Clip length, flange range, made to drawing |
| Certification | Material Test Certificate, EN 10204 3.1 |
| Packaging | Boxed in standard counts, bulk cartons, or private label to customer specification |
